During the transparent learn cycle, the CacheVault power module consumes up to an additional 6W. The PCIe 3.3V rail
supplies the power for the learn cycle.
HBA Tri-Mode Storage Adapter Power Supply Requirements
The following table describes the typical power consumption of the HBAs.
Table 28: HBA Tri-Mode Storage Adapter Typical Power Consumption
Typical Power (W)
Power Mode
9500-16i 9500-8i 9500-16e 9500-8e
3.3V Supply 0.04 0.02 0.04 0.02
+12V Supply 8.5 5.94 8.70 6.10
Total Power 8.9 5.96 8.74 6.12
Broadcom 95xx-MR-HBA-Tri-Mode-UG104
34
