Broadcom 95 Series User Manual

Broadcom 95xx User Guide Broadcom
®
95xx PCIe 4.0 MegaRAID
®
and HBA Tri-Mode Storage Adapters
Revision History
Version 2.3, May 1, 2020
•
Updated PCIe (NVMe) Support.
Version 2.2, March 17, 2020
•
Added connector identifiers to drawings in Broadcom MegaRAID and HBA Tri-Mode Storage Adapter Characteristics.
•
Template update.
Version 2.1, February 12, 2020
•
Changed the relative humidity range and temperature range for operating conditions in Operating and Nonoperating
Conditions.
•
Updated the cable drawing in Cable 05-60002-00.
•
Added Cable 05-60006-00 and Cable 05-60007-00.
Version 2.0, December 17, 2019
•
Updated Operating System Support.
•
Removed Chapter 5 section, Backplanes with Mini-SAS HD Connectors.
•
Updated Figure 3.
•
Added External Adapter Connector Pinout, Virtual Pin Port Management, Sideband Signals, and Cable Drawings and
Pinouts.
•
Updated board dimensions in HBA 9500-16e Adapter – Connector and LED Designations, and HBA 9500-8e Adapter
– Connector and LED Designations.
•
Updated connector and LED locations in MegaRAID 9580-8i8e Adapter – Connector and LED Designations.
Preliminary, Version 1.0, September 27, 2018
Initial document release.
Broadcom 95xx-MR-HBA-Tri-Mode-UG104
46

Broadcom 95 Series Specifications

General

Brand	Broadcom
Model	95 Series
Category	PCI Card
Language	English
