NetXtreme II User Guide
January 2010
Broadcom Corporation
Page 166 Using Broadcom Advanced Control Suite 3 Document ENGSRVT52-CDUM100-R
Bus No. Indicates the number of the bus where the adapter is installed.
Device No. The number assigned to the adapter by the operating system.
Function No. The port number of the adapter. For a single-port adapter, the function number is 0. For a two-port adapter,
the function number for the first port is 0, and the function number for the second port is 1.
Interrupt Request. The interrupt line number that is associated with the adapter. Valid numbers range from 2 to 25.
Memory Address. The memory mapped address that is assigned to the adapter. This value can never be 0.
MSI Version. This is the Message Signaled Interrupts (MSI) version being used. The option MSI corresponds to the PCI 2.2
specification that supports 32 messages and a single MSI address value. The option MSI-X corresponds to the PCI 3.0
specification that supports 2,048 messages and an independent message address for each message.
