1000/2500BASE-X FIBER OPTIC SPECIFICATIONS
INTERFACE SPECIFICATIONS
Table 3: 1000/2500BASE-X Fiber Optic Specifications
Port Type Connector Media Maximum Distance
1000BASE-X Small form-factor pluggable
(SFP) transceiver with LC™
connection system
(Infineon p/n V23818-K305-
L57)
Multimode fiber (MMF)
System optimized for 62.5/
50 µm graded index fiber
550m (1804 feet)
2500BASE-X
1
Small form-factor pluggable
(SFP) transceiver with LC™
connection system
(Finisar p/n
FTLF8542E2KNV)
Multimode fiber (MMF)
System optimized for 62.5/
50 µm graded index fiber
550m (1804 feet)
1
Electricals leveraged from IEEE 802.3ae-2002 (XAUI). 2500BASE-X is term used by Broadcom to describe 2.5 Gbit/s
(3.125GBd) operation. LC is a trademark of Lucent Technologies.
Table 4: 10/100/1000BASE-T Performance Specifications
Feature Specification
PCI Express Interface x4 link width
10/100/1000BASE-T 10/100/1000 Mbps
Table 5: 10GBASE-T Performance Specifications
Feature Specification
PCI Express Interface x8 link width
10GBASE-T 10 Gbps
