NetXtreme II User Guide
January 2010
Broadcom Corporation
Page 168 Using Broadcom Advanced Control Suite 3 Document ENGSRVT52-CDUM100-R
Vendor ID. The vendor ID.
Device ID. The adapter ID.
Subsystem Vendor ID. The subsystem vendor ID.
Subsystem ID. The subsystem ID.
External PHY Firmware Version. The external PHY firmware version.
TESTING THE NETWORK
The Network Test option on the Diagnostics tab lets you verify IP network connectivity. This test verifies if the driver is
installed correctly and tests connectivity to a gateway or other specified IP address on the same subnet.
The network test uses TCP/IP to send ICMP packets to remote systems, then waits for a response. If a gateway is
configured, the test automatically sends packets to that system. If a gateway is not configured or if the gateway is
unreachable, the test prompts for a destination IP address.
NOTE: The network test option is not available on adapters that are grouped into a team (see Configuring
Teaming).
To run the network test
1. Click the name of the adapter to test in the Device Management pane.
2. Click the Diagnostics tab. If the Diagnostics tab is not visible, then from the View menu, select Navigate, then Device
Management, and then Diagnostics.
3. From the Select a test to run list, select Network Test. If the Network Test option is not available, then from the
Context View tab on the right side of the window, select Diagnostics and then select Network Test.
4. To change the destination IP address, select IP address to ping, then click the browse button (…). In the Network Test
window, enter a Destination IP address, then click OK.
5. Click Run.
The results of the network test are displayed in the Result field.
