User Guide NetXtreme II
January 2010
Broadcom Corporation
Document ENGSRVT52-CDUM100-R Wake On LAN Power Requirements Page 213
WAKE ON LAN POWER REQUIREMENTS
ENVIRONMENTAL SPECIFICATIONS
Table 10: BCM5708C Wake On LAN Power Requirements (Nominal Conditions)
100 Mbit Link 10 Mbit Link
NIC 3.3V Current (mA) NIC Power (W) NIC 3.3V Current (mA) NIC Power (W)
236 0.78 150 0.5
Table 11: BCM5709C Wake On LAN Power Requirements (Nominal Conditions)
100 Mbit Link 10 Mbit Link
NIC 3.3V Current (mA) NIC Power (W) NIC 3.3V Current (mA) NIC Power (W)
00.87 00.85
Table 12: BCM5708 Environmental Specifications
Condition Operating Specification Storage Specification
Temperature 0°C to 55°C (+32°F to +131°F) –40°C to +85°C (–40°F to +185°F)
Relative humidity 5% to 85% (noncondensing)
40°C, 16 hour dwells at extremes
5% to 95% (noncondensing)
10°C/hour
Altitude Up to 10,000 ft. Up to 35,000 ft.
Shock 10g, 1/2 sine wave, 11 ms 60g, 1/2 sine wave, 11 ms
Vibration, peak to peak displacement 0.005 in. max (5 Hz to 32 Hz) 0.1 in. max (5 Hz to 17 Hz)
Vibration, peak acceleration 0.25g (5 Hz to 500 Hz)
(Sweep Rate = 1 octave/min.)
0.25g (5 Hz to 500 Hz)
(Sweep Rate = 1 octave/min.)
Table 13: BCM5709 Environmental Specifications
Parameter Condition
Operating Temperature 0°C to 55°C
Air Flow Requirement (LFM) 0
Storage Temperature –40°C to +65°C
Storage Humidity 5% to 95% condensing
Vibration and Shock IEC 68, FCC Part 68.302, NSTA, 1A
Electrostatic/Electromagnetic Susceptibility EN 61000-4-2, EN 55024
