Broadcom NetXtreme II User Manual

NetXtreme II User Guide
January 2010
Broadcom Corporation
Page 88 iSCSI Boot Document ENGSRVT52-CDUM100-R
x64 Architecture
• Disk1: "WDF Installation Disk"
• bxvbd.cat
• bxvbd.inf
• bxvbda.sys
• txtsetup.oem
• wdf01000.sys
•wdfldr.sys
• Disk2: "Broadcom iSCSI Driver"
•bxois.cat
•bxois.inf
•bxois.sys
• txtsetup.oem
To perform an iSCSI remote installation
1. During system POST, enter the MBA configuration menu CTRL+S when prompted.
2. Set Boot protocol to iSCSI
3. Enter the iSCSI configuration menu by selecting CTRL+K.
4. Fill in General Parameters as required. Set Boot to iSCSI target to Disable.
5. Fill in Initiator and Target parameters as required.
6. Exit and save the iSCSI configuration.
7. Exit and save the MBA configuration.
8. Reorder the BIOS boot order so that the Broadcom iSCSI adapter precedes the CDROM.
9. Insert the Windows Server 2003 SP2 Slipstreamed CD.
10. Verify the offload iSCSI BIOS boot code successfully opens a session with the remote iSCSI target.
11. Continue to boot with the Windows Server installation CD.
12. Press F6 when prompted to install additional drivers.
13. Press S to install additional drivers. Insert Disk 1 "WDF Installation Disk" when prompted. Select Load 1st: wdfldr.
14. Press S to install additional drivers. Insert Disk 1 "WDF Installation Disk" when prompted. Select Load 2nd: wdf01000.
15. Press S to install additional drivers. Insert Disk 1 "WDF Installation Disk" when prompted. Select Load 3rd: Broadcom
Virtual Bus Driver.
16. Press S to install additional drivers. Insert Disk 1 "WDF Installation Disk" when prompted. Select Load 4th: Broadcom
iSCSI Driver.
17. Continue with Windows text mode installation as usual.
18. The system will reboot after text mode setup. During POST, reenter the MBA configuration menu by selecting CTRL+S
when prompted.
19. Enter the iSCSI configuration menu by selecting CTRL+K.
20. Enter General Parameters and set Boot to iSCSI target to Enable.
21. Exit and save the iSCSI configuration.
22. Exit and save the MBA configuration.
23. Continue with Windows GUI mode installation as usual.
