6-2
OPERATIONAL LOCKOUTS
Indicator lights illuminate to show “Opera-
tion Lockout” conditions that need to be
corrected before unit will function.
15. Product Door Indicator Light: Illumi-
nates when the Product Door is open.
16. Access Door Indicator Light: Illumi-
nates when the Access Door is open
or when Access Door Latch is improp-
erly latched.
17. Element Up Indicator Light: Illumi-
nates when the heating element is in
the raised position.
18. Air Flow Indicator Light: Illuminates
when the flow of air through the Air Fil-
ter area falls below acceptable level.
Replace Air Filter every 3
months.
19. Air Filter Indicator Light: Illuminates
when the air filter is not installed in the
unit.
20. Grease Filter Indicator Light: Illumi-
nates when the grease filter is not
installed in the unit.
21. Hi-Limit Control Indicator Light:
Prevents oil temperature from exceed-
ing 475° F. If power to control turns off
due to Hi-Limit Control, this indicator
light will illuminate, press the OFF but-
ton and DO NOT attempt to operate
until it has been serviced by an autho-
rized Broaster Company representa-
tive.
22. Fire System Light: Illuminates when
6 months have passed to indicate
semi-annual maintenance is due on
fire suppression system.
CONTROLLER BASIC
PROGRAMMING
NORMAL OPERATING MODE
Check oil level before
pressing the ‘ON’ button.
Action: Press ‘ON’ button.
Response: Temp Display alternates
between number values for cook tempera-
ture, and LO (idle mode). LO will disappear
when oil temperature has reached cook
temperature value. Time Display will show
the set time in minutes and seconds.
Set Temperature:
Action: Press Cook Temperature But-
ton twice within 5 seconds.
Response: Programming mode has
been entered. Flashing Temp Display reads
“###F.” (### = temperature value ie: 360F)
Action: If desired, press keypad num-
bers to change displayed value then press
Cook Temperature Button once to enter
new value into memory.
Response: Controller returns to idle
mode.
Set Time:
Action: Press Cook Time Button twice
within 5 seconds.
Response: Programming mode has
been entered. Flashing Time Display reads
“##:##.” (##:## = time value ie: 08:00)
Action: If desired, press key pad num-
bers to change displayed value in minutes
and seconds then press Cook Time Button
once to enter new value into memory.
Response: Controller returns to idle
mode.
boraster.com Manual #16421 5/06 Rev 4/14
