Brookfield Engineering Laboratories, Inc. Page 11 Manual No. M/92-021-N0902
NOTE: You have approximately three seconds in which to press the SELECT SPINDLE
key before the blinking stops. If you fail to press the SELECT SPINDLE key
before the blinking stops you will have to repeat the above steps and re-select the
desired spindle.
The DV-I+ will begin to calculate using the new spindle parameters as soon as the SELECT
SPINDLE key is pressed the second time.
Tp
II.2.2 Spindle Section for Models WITH Temperature Display
The steps for selecting and accepting a spindle entry are the same as Section II.2.1 except that
when
SELECT SPINDLE is depressed, the temperature display is temporarily replaced by the spindle
entry code until the entry code is accepted (Figure II-6):
cP 123.4 SP31
10 RPM % 89.7
Figure II-6
Once the spindle entry code is accepted, the screen will return to the default display:
cP 0.0 70.1°F
0.0RPM % 0.0
Figure II-7
The DV-I+ may also be programmed at Brookfield Engineering for “special” user spindles.
These “special” spindles will show up on the spindle scroll list starting with the designation "AA"
and continuing through "AZ". Contact Brookfield Engineering regarding your needs for special
spindles.
