Brookfield DV-I+ Series User Manual

Brookfield Engineering Laboratories, Inc. Page 30 Manual No. M/92-021-N0902
Appendix D - Spindle and Model Codes
Each spindle has a two digit code which is scrolled to via the keypad on the DV-I+. The spindle code
directs the DV-I+ to calculate viscosity for the spindle that is being used. The spindle multiplyer
constant (SMC) is used to calculate full scale viscosity range for any spindle/speed combination (refer
to Appendix E). Spindle codes are listed in Table D-1.
SPINDLE CODE SMC
RV1 01 1
RV2 02 4
RV3 03 10
RV4 04 20
RV5 05 40
RV6 06 100
RV7 07 400
HA1 01 1
HA2 02 4
HA3 03 10
HA4 04 20
HA5 05 40
HA6 06 100
HA7 07 400
HB1 01 1
HB2 02 4
HB3 03 10
HB4 04 20
HB5 05 40
HB6 06 100
HB7 07 400
LV1 61 6.4
LV2 62 32
LV3 63 128
LV4 64 640
LV5 65 1280
SPIRAL 70 105
T-A 91 20
T-B 92 40
T-C 93 100
T-D 94 200
T-E 95 500
T-F 96 1000
SPINDLE CODE SMC
ULA 00 0.64
DIN-ULA 85 1.22
TSEL-DIN-81 81 3.7
SSA-DIN-82 82 3.75
SSA-DIN-83 83 12.09
ULA-DIN-85 85 1.22
ULA-DIN-86 86 3.65
ULA-DIN-87 87 12.13
SC4-14 14 125
SC4-15 15 50
SC4-16 16 128
SC4-18 18 3.2
SC4-21 21 5
SC4-25 25 512
SC4-27 27 25
SC4-28 28 50
SC4-29 29 100
SC4-31 31 32
SC4-34 34 64
SC4-37 37 25
CPE40 40 0.327
CPE41 41 1.228
CPE42 42 0.64
CPE51 51 5.178
CPE52 52 9.922
V-71 71 2.62
V-72 72 11.10
V-73 73 53.50
Table D-1
