Brookfield Engineering Laboratories, Inc. Page 41 Manual No. M/92-021-N0902
Figure H-1
*Provided with instruments shipped after October 1, 1999. Replaced Model A Laboratory Stand.
Appendix H - Model S Laboratory Stand with Parts Identification*
ITEM PART #
10
9
8
7
6
5
4
3
2
1
2
1
1
1
1
1
1
2
1
OPTIONAL
QTY.
VS-29W
VS-29
VS-41Y
VS-40Y
VS-35
502020032S34Z
50S311824S06B
VS-3
VS-2
VS-34
VS-38
1
DESCRIPTION
BELLEVILLE SPRING WASHER
TENSION INSERT
CLAMP SCREW ASSEMBLY
GEAR SCREW ASSEMBLY
CLAMP
LOCKWASHER, EXTERNAL TOOTH, 5/16 X 5/8 X 1/32
SCREW, 5/16-18 X 3/4 LG. SLOTTED PAN HD.
LEVELING SCREW
BASE
14” UPRIGHT ROD
18” UPRIGHT ROD
11 1VS-28 TENSION SCREW
VS-35Y
MODEL S
CLAMP ASSEMBLY
2
3
4
5
1
8
6
7
9
10
11
BROOKFIELD
LABORATORY
VISCOMETER
