Brookfield Engineering Laboratories, Inc. Page 43 Manual No. M/92-021-N0902
Figure H-2
**Provided with instruments shipped before October 1, 1999
Model A Laboratory Stand**
1 VS-20 UPRIGHT ROD 1
2 VS-1 BASE 1
3 VS-3 LEVELING SCREW 3
4 VS-21 JAM NUT 1
5 VS-35 CLAMP 1
6 VS-40Y GEAR SCREW ASSEMBLY 1
7 VS-41Y CLAMP SCREW ASSEMBLY 1
8 VS-29 TENSION INSERT 1
9 VS-29W BELLEVILLE SPRING WASHER 2
10 VS-28 TENSION SCREW 1
11 50S103208S25B SCREW, 4-40 X 3/8 LG. SOC. HD. CAP, 18-8 SS 1
BLM-4E ROD EXTENSION-4" LONG OPTIONAL
BLM-4E2 RODE EXTENSION - 8" LONG OPTIONAL
12
