AMETEK Brookeld Page 25 Manual No. M15-356-B0916
Small Sample Adapter and Thermosel
SSA and
ermosel
Spindle
Viscosity Range (cP)
Shear Rate sec-1
DVELV
SC4-16
120 - 400,000 .29N
SC4-18
3 - 10,000 1.32N
SC4-25
480 - 1,600,000 .22N
SC4-31
30 - 100,000 .34N
SC4-34
60 - 200,000 .28N
SC4-81
3 - 10,000 1.29N
SC4-82
3 - 10,000 1.29N
SC4-83
11 - 38,000 1.29N
N = RPM
SSA and
ermosel
Spindle
Viscosity (cP) Shear Rate
sec-1
DVERV DVEHA DVEHB
SC4-14 1,250 - 4,165,000 2,500 - 8,330,000 10,000 - 33,360,000 .40N
SC4-15 500 - 1,660,000 1,000 - 3,320,000 4,000 - 13,280,000 .48N
SC4-21 50 - 167,000 100 - 334,000 400 - 1,336,000 .93N
SC4-27 250 - 830,000 500 - 1,660,000 2,000 - 6,640,000 .34N
SC4-28 500 - 1,660,000 1,000 - 3,320,000 4,000 - 3,280,000 .28N
SC4-29 1,000 - 3,330,000 2,000 - 6,660,000 8,000 - 26,640,000 .25N
ermosel
SC4-81
37 - 10,000 73.0 - 10,000 292 - 10,000 1.29N
SSA
SC4-82
37 - 10,000 73.0 - 10,000 292 - 10,000 1.29N
SSA
SC4-83
121 - 50,000 243 - 50,000 970 - 50,000 1.29N
N = RPM
UL Adapter
UL Spindle
Viscosity (cP)
Shear Rate
sec-1
DVELV DVERV DVEHA DVEHB
YULA-15 or 15Z 1 - 2,000 7 - 2,000 13 - 2,000 52 - 2,000 1.22N
ULA-DIN-Y 1 - 3,800 11 - 5,000 22 - 5,000 85 - 2000 1.29N
N = RPM
