AMETEK Brookeld Page 30 Manual No. M15-356-B0916
Appendix C - Spindle Entry Codes and SMC/SRC Values
When using a standard Brookeld Digital Viscometer, each spindle has a two digit entry code
which is entered via the keypad on the DVE. e entry code allows the DVE to calculate Viscosity.
Each spindle has two constants which are used in these calculations. e Spindle Multiplier
Constant (SMC) used for viscosity and shear stress calculations, and the Shear Rate Constant
(SRC), used for shear rate and shear stress calculations.
Table C-1
(Continued on following page)
SPINDLE ENTRY SMC SRC
RV1 01 1 0
RV2 02 4 0
RV3 03 10 0
RV4 04 20 0
RV5 05 40 0
RV6 06 100 0
RV7 07 400 0
HA1 01 1 0
HA2 02 4 0
HA3 03 10 0
HA4 04 20 0
HA5 05 40 0
HA6 06 100 0
HA7 07 400 0
HB1 01 1 0
HB2 02 4 0
HB3 03 10 0
HB4 04 20 0
HB5 05 40 0
HB6 06 100 0
HB7 07 400 0
LV1 61 6.4 0
LV2 62 32 0
LV3 63 128 0
LV4 or 4B2 64 640 0
LV5 65 1280 0
LV-2C 66 32 0.212
LV-3C 67 128 0.210
SA-70 70 105 0.677
T-A 91 20 0
T-B 92 40 0
T-C 93 100 0
