Table C-2 lists the model codes and spring torque constants for each viscometer model.
VISCOMETER MODEL
TORQUE
CONSTANT TK
MODEL CODE ON DVE
SCREEN
DVELV 0.09375 LV
2.5xDVELV 0.234375 2.5LV
5xDVELV 0.46875 5LV
12DVELV 1.125 12LV
1/4DVERV 0.25 1/4RV
1/2DVERV 0.5 1/2RV
DVERV 1 RV
DVEHA 2 HA
2xDVEHA 4 2HA
2.5xDVEHA 5 2.5HA
DVEHB 8 HB
Table C-2
e full scale viscosity range for any DVE model and spindle may be calculated using the equation:
Full Scale Viscosity Range [cP] = TK
*
SMC
*
10,000
RPM
where:
TK = DVE Torque Constant from Table C-2
SMC = Spindle Multiplier Constant from Table C-1
e Shear Rate calculation is:
Shear Rate (
1
/
Sec
) = SRC
*
RPM
where:
SRC = Shear Rate Constant from Table C-1
