e guard leg is a part of the calibration check of the Brookeld LV and RV series Viscometer. Our
customers should be aware of its existence, its purpose and the eect that it may have on data. With
this knowledge, the viscometer user may make modications to the recommended method of operation
to suit their needs.
4 11/16
1 7/163 3/16
5 9/32
B-21Y
Guard Leg
For RV Torque
B-20Y
Guard Leg
For LV Torque
Figure F-1 - Brookeld Guard Leg
