AMETEK Brookeld Page 8 Manual No. M15-356-B0916
16 9/32
[41.3 cm]
7 3/8
[18.7 cm]
14 7/8
[37.8 cm]
10 31/32
[27.9 cm]
3 3/16
[8.1 cm]
5 3/16
[13.2 cm]
13 13/32
[34.1 cm]
9 15/32
[24.1 cm]
DVE VISCOMETER
VS-1
LAB STAND BASE ASSEMBLY
B-21Y
RV GUARD LEG
ASSEMBLY
7 51/64
[19.8 cm]
Figure I-2
