Replacing the Needle 37
1
— — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —
c
Using the screwdriver, loosen the needle
clamp screw.
d
Lower the needle-changing tool.
X The needle can be removed from the needle
bar.
e
Insert the new needle into the hole in the
needle-changing tool.
Insert the needle with the flat side of the needle
toward the rear of the machine.
f
Lift up the needle-changing tool so that the
fork hooks onto the needle clamp screw.
g
Insert the needle until it touches the needle
stopper, and then use the screwdriver to
tighten the needle clamp screw.
X The needle is installed.
h
Lower the needle-changing tool off of the
needle.
Note
z The needle-changing tool can not be used
for the twin needle.
