Brother DCP-8080DN User Manual

Scanning
166
9
Pre-Scanning an image 9
The PreScan button is used to preview and also lets you crop any unwanted areas from the image. When
you are satisfied you are scanning the correct area, click the Start button in the Scanner Setup dialog box to
scan the image.
a Load your document.
b Click PreScan.
The whole image is scanned into your Macintosh
®
and appears in the Scanning Area.
c Drag the mouse pointer over the portion you want to scan.
d Put the document in the ADF again.
Note
If you put the document on the scanner glass in step a, skip this step.
e Adjust the settings for Resolution, Scan Type, Brightness and Contrast in the Scanner Setup dialog
box as needed.
f Click Start.
This time only the chosen area of the document appears in the application window.
g You can refine the image in your editing software.

Brother DCP-8080DN Specifications

General

Zoom capability	25 - 400%
Maximum print size	-
Standard input capacity	250 sheets
Color scanning	Yes
Enhanced scan resolution	19.200 x 19.200 DPI
Print technology	Laser
Time to first page (black, normal)	8.5 s
Standard interfaces	USB 2.0/RJ-45
Built-in processor	NEC VR5500
Internal memory	64 MB
Compatible operating systems	Windows/Mac OS
Type	Digital copier
Sustainability certificates	ENERGY STAR
Power consumption (standby)	16 W
Power consumption (typical)	680 W
Operating relative humidity (H-H)	20 - 80 %
Maximum operating temperature range (T-T)	50 - 91 °C
Pallet dimensions (W x D x H)	627.38 x 566.42 x 574.04 mm
Processor model	VR5500
Processor family	NEC

Weight and Dimensions

Weight	18098 g
Package weight	22000 g
Maximum dimensions (W x D x H)	530.86 x 449.58 x 474.98 mm
