3-17

Confidential

9 Top side of the machine

Harness colors are subject to change for some reason.

HVPS flat cable

Toner box relay flat cable *

1

/MP relay flat cable *

2

Main PCB ASSY

Polygon motor harness (WH)

*

1

For models with Toner box

*

2

For MP models
