CHAPTER 1 GENERAL
1-4
2. OVERVIEW
<Front View>
*The printer illustration is based on HL-5150D and HL-5170DN.
Fig. 1-1
<Rear View>
*The printer illustration is based on HL-5170DN.
Fig. 1-2
Support Flap
Face-up Output
Tray
Front cover
Control Panel
(HL-5170DN)
LED (Light-
emitting Diode)
(HL-5130/5140) Manual Feed Tray
(HL-5150D/5170DN)
Multi-purpose Tray (MP Tray)
Front Cover
Release Button
Power Switch
Paper Tray
Side Cove
r
USB Interface
Connector
(HL-5170DN)
10/100Baser TX Port
Parallel Interface Connector
A
C Power
Connector
Face-down
Out
p
ut Tra
y
Support Flap S
Duplex Tray (HL-
5150D/HL-5170DN)
