3-11

Confidential

3 Top side of the machine

Harness colors are subject to change for some reason.

HVPS flat cable

Main PCB ASSY

Polygon motor harness (WH)

Toner box relay flat cable*

1

/MP relay flat cable*

2

*

1

For models with Toner box

*

2

For MP models
