3-5
Confidential
Low-voltage power supply PCB ASSY
Screw cup M3x8 (black) 2
0.45±0.05 (4.5±0.5)
High-voltage power supply PCB ASSY
Screw cup M3x8 (black) 1
0.45±0.05 (4.5±0.5)
Toner box relay PCB ASSY
(For models with toner box)/
MP relay PCB ASSY (For MP models)
Taptite bind B M4x12 1
0.8±0.1 (8±1)
Toner box new PCB ASSY
(For models with toner box)
Taptite bind B M3x8 1
0.45±0.05 (4.5±0.5)
Laser unit Taptite cup S M3x8 SR 4
0.8±0.1 (8±1)
Main PCB FG plate 1 Screw cup M3x8 (black) 2
0.6±0.1 (6±1)
Main PCB ASSY Screw cup M3x8 (black) 4
0.6±0.1 (6±1)
MP frame parts (For MP models) Taptite bind B M4x12 3
0.8±0.1 (8±1)
Taptite pan B M4x14 1
0.8±0.1 (8±1)
Front chute ASSY For manual
feed models
Taptite bind B M4x12 2
0.8±0.1 (8±1)
Screw pan (S/P washer)
M3x12DB
1
0.5±0.1 (5±1)
For MP models Taptite bind B M4x12 3
0.8±0.1 (8±1)
Frame L unit Taptite bind B M4x12 (11a)
(Under bar)
1
0.8±0.1 (8±1)
Taptite cup S M3x6 SR (11b)
(for securing the
chute
ground plate
)
1
0.5±0.1 (5±1)
Taptite bind B M4x12 (11c)
(for securing the
registration chute)
1
0.8±0.1 (8±1)
Taptite cup S M3x8 SR (11d)
(for securing the laser L FG plate)
1
0.8±0.1 (8±1)
Taptite bind B M4x12 (12a) 2
0.8±0.1 (8±1)
Taptite cup S M3x8 SR (12b)
2
0.8±0.1 (8±1)
Flat cable guide Taptite bind B M4x12 1
0.8±0.1 (8±1)
Laser L FG plate Screw pan (S/P washer)
M3x12DB
1
0.5±0.1 (5±1)
Motor drive sub ASSY Taptite bind B M4x12 3
0.8±0.1 (8±1)
Taptite cup S M3x8 SR 1
0.8±0.1 (8±1)
Paper feed motor Screw bind M3x4 3
0.65±0.05 (6.5±0.5)
Toner box drive cover Taptite bind B M4x12 2
0.8±0.1 (8±1)
Toner sensor PCB ASSY Taptite bind B M3x8 1
0.4±0.05 (4±0.5)
Holder toner box Taptite bind B M4x12 3
0.8±0.1 (8±1)
Lift cam guide Taptite bind B M4x12 1
0.8±0.1 (8±1)
Main shield plate Taptite cup S M3x8 SR 1
0.5±0.1 (5±1)
Screw pan (S/P washer)
M3x12DB
1
0.5±0.1 (5±1)
LVPS shield plate Taptite cup S M3x8 SR 1
0.55±0.05 (5.5±0.5)
Taptite bind B M4x12 1
0.8±0.1 (8±1)
Frame R unit Taptite cup S M3x6 SR 1
0.5±0.1 (5±1)
Taptite bind B M4x12 2
0.8±0.1 (8±1)
Registration front/rear actuator
holder ASSY
Taptite bind B M3x10 1
0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
