3-11
Confidential
3 Document scanner unit
Harness colors are subject to change for some reason.
Document scanner unit
First side CIS flat cable
Document scanner
motor harness
(WH)
Panel flat cable
First side CIS
flat cable
Panel flat cable
FB ground harness (BK)
Document scanner
motor harness
(WH)
Main PCB ASSY
ADF FFC holder
Panel ground harness (BK)
Panel ground harness (BK)
