Brother MFC-7860DW Service Manual

1-1
Confidential
1. SPECIFICATIONS LIST
1.1 General
Specifications are subject to change without notice.
Model
DCP-7055
DCP-7057
DCP-7057E
DCP-7055W
DCP-7057W
DCP-7060D DCP-7065DN
DCP-7070DW
HL-2280DW
Print method Electrophotographic / Laser
Resolution 600 dpi x 600 dpi, HQ1200 (2400 X 600 dpi) quality
Print speed Up to 20/21 ppm Up to 24/24
ppm
Up to 26/27 ppm
* When loading A4 or Letter-size paper from the paper tray.
Warm-up time From Sleep Mode: Less than 7 seconds
* At 23°C (73.4F)
From Power OFF → ON: Less than 27 seconds From Power
OFF → ON:
Less than
28 seconds
* At 23°C (73.4F)
First print
time
From Ready
mode
Less than 10.0 seconds Less than 8.5 seconds
From Sleep
mode
Less than 19.0 seconds Less than 16.5 seconds
CPU ARM9 200MHz
Memory 16 MB 32 MB
Backup Clock
N/A
Interface Hi-Speed
USB 2.0
Hi-Speed USB
2.0,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Hi-Speed
USB 2.0
Hi-Speed
USB 2.0,
Ethernet 10/
100 BASE-
TX
Hi-Speed USB
2.0, Ethernet
10/100 BASE-
TX,
IEEE802.11b/g
(Infrastructure
Mode / Adhoc
Mode)
Power
Consumption
* Measured
with only
USB
connected
Peak 1080 W
Copying Average: Approximately 445 W
Ready Average: Approximately 55 W
Sleep,
Wireless
LAN: ON
N/A Average:
Approximately
2.8 W
N/A Average:
Approximately
2.8 W
Deep Sleep Average:
Approximately
0.9 W
Average:
Approximately
1.0 W
Average: Approximately
0.9 W
Average:
Approximately
1.0 W

Brother MFC-7860DW Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	26 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Internal memory	32 MB
Processor family	ARM
Processor frequency	200 MHz
Card reader integrated	No
Sound pressure level (copying)	53 dB
Sound pressure level (printing)	30 dB
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Dimensions (WxDxH)	527 x 510 x 493 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	- pages per month
Package weight	11600 g

Weight and Dimensions

Weight	14800 g
