Brother MFC-8860DN Servise Manual

Confidential
9-7
Error Code
(Hex)
Symptom Probable Cause Solution
The paper ejection
roller does not rotate
correctly
Replace the paper ejection
roller.
Foreign materials in the
paper path.
Remove foreign materials.
Registration sensor
actuator caught on the
surrounding parts
Correct the surrounding
parts on which the
actuator caught.
Registration sensor
broken
Replace the sensor PCB.
84 Recording paper jam.
(The registration sensor stays
ON after completion of paper
ejection operation.)
Main PCB defective Replace the main PCB.
85 No paper tray1 loaded. Tray 1 is not closed
completely.
Close the tray1.
86 No paper tray2 loaded. Tray 2 is not closed
completely.
Close the tray2.
87 Not used.
Recording paper not
loaded correctly
Instruct the user to load
the recording
Registration sensor
broken
Replace the registration
sensor.
Separation pad
damaged
Replace the paper tray.
Objects, such as bits of
paper or chips, are in
the paper tray or paper
tray
Remove the objects from
the paper tray.
Paper pick up roller
defective
Replace the paper pick up
roller.
Paper feed motor
broken
Replace the paper feed
motor ASSY.
88 Recording paper jam. (Even
after paper pulling-in
operation, the registration
sensor is still OFF.)
Main PCB defective Replace the main PCB.
89 Not used.
8A Jam tray2 Paper jams in tray2 Pull the jammed paper out
of the indicated area.
8B Jam tray1 Paper jams in tray1 Pull the jammed paper out
of the indicated area.
8C Jam MP tray Paper jams in MP tray Pull the jammed paper out
of the indicated area.
8D-A0 Not used.
A1 Front cover opened. Hook of the front open
switch on the front
cover broken
Replace the front cover
switch.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
