Brother MFC-8860DN Servise Manual

Confidential
9-8
Error Code
(Hex)
Symptom Probable Cause Solution
Front open switch
broken
Replace the front open
switch.
A2 Document length exceeding
the scan limitation.
During scanning, 90 cm or
longer of a document is
detected.
During document feeding or
ejecting, 400 cm or longer of a
document is detected.
Document jam Remove the jammed
document.
Document jam Remove the jammed
document.
Document rear sensor
actuator caught on the
surrounding parts
Correct the surrounding
parts on which the
actuator caught.
A3
The document rear sensor does
not come ON during document
pull-in operation.
Document rear sensor
broken
Replace the document
rear sensor.
A4 50% or more faulty of white
level data. (Not used.)
A5
FAX scanning failure.
(1st time)
CCD defective
White-level reference
film stained in the
scanner cover
Replace the scanner cover
(scanner unit).
A6 FAX scanning failure. (retry)
Main PCB defective Replace the main PCB.
A7-A9 Not used.
AA The document cover is opened
when the ADF is used.
Document cover sensor
defective
(Remove the document on
ADF, then close the
document cover.)
Replace the document
cover sensor.
AB Not used.
AC Less than 50% faulty of white
level data. (Not used.)
AD-AE Not used.
Scanner lock lever is
not released.
Open the document cover
and release the scanner
lock lever.
Press the [Stop/Exit] key.
AF
The scanner is locked.
Scanner lock lever
defective
Replace the scanner lock
lever.
B0 Not used.
CCD defective Replace the CCD unit. B1 Dark level offset data level
error for scanning.
Main PCB defective Replace the main PCB.
CCD defective Replace the CCD unit.
B2
Gain control data level error
for scanning.
Main PCB defective Replace the main PCB.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
