Brother MFC-8860DN Servise Manual

App. 4-33 Confidential
WSW29
(Function setting 7)
Selector
No.
Function
Setting and Specifications
1
|
3
Compression threshold level
for voice signals inputted via
the telephone line in the built-
in TAD operation
(Not used.)
No. 1 2 3
0 0 0 : -47.0 dBm (A)
0 0 1 : -48.5 dBm (B)
0 1 0 : -50.0 dBm (C)
0 1 1 : -51.5 dBm (D)
1 0 0 : -53.0 dBm (E)
1 0 1 : -54.5 dBm (F)
1 1 0 : -56.0 dBm (G)
1 1 1 : OFF (H)
4
|
6
Compression threshold level
for voice signals inputted via
the handset in the built-in TAD
operation (Not used.)
No. 4 5 6
0 0 0 : -44.0 dBm (A)
0 0 1 : -45.5 dBm (B)
0 1 0 : -47.0 dBm (C)
0 1 1 : -48.5 dBm (D)
1 0 0 : -50.0 dBm (E)
1 0 1 : -51.5 dBm (F)
1 1 0 : -53.0 dBm (G)
1 1 1 : OFF (H)
7
Impedance switching control in
pulse dialing (Not used.)
0: OFF 1: ON
8
Prompt beep when the memory
area for the activity report
becomes full (Not used.)
0: No 1: Yes
NOTE: Selectors 1 through 6 are applicable to models equipped with built-in TADs.
NOTE: Selectors 7 and 8 are applicable only to the European versions.
- Selectors 1 through 6: Compression threshold level for voice signals inputted via the telephone line in
the built-in TAD operation (Not used.)
If voice signals inputted via the telephone line are below the level specified by these selectors, the
TAD interprets those received voice signals as no signal, compressing the recording time.
- Selector 8: Prompt beep for activity report (Not used.)
This selector determines whether or not to beep if the memory area for the activity report becomes
full, for prompting you to print out the report. (Printing it out will clear the memory area.)

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
