Brother MFC-8860DN Servise Manual

App. 4-34 Confidential
WSW30
(Function setting 8)
Selector
No.
Function
Setting and Specifications
1
|
3
Dial tone/busy tone detection
level during recording of ICM
(Not used.)
No. 1 2 3
0 0 0 : -38.0 dBm (A)
0 0 1 : -39.5 dBm (B)
0 1 0 : -41.0 dBm (C)
0 1 1 : -42.5 dBm (D)
1 0 0 : -44.0 dBm (E)
1 0 1 : -45.5 dBm (F)
1 1 0 : -47.0 dBm (G)
1 1 1 : -48.5 dBm (H)
4
Duty cycle control of pulsed
current for the heat-fuser unit
0: OFF 1: ON
5 "CLEAN DRUM" display 0: Yes 1: No
6
7
Not used.
0: Normal 1: Dark
8
Text mode copy density
adjustment
0: Normal 1: Dark
NOTE: Selectors 1 through 3 are applicable to models equipped with internal TADs.
NOTE: Selectors 4 is applicable to the European version only.
- Selectors 1 through 3: Dial tone/busy tone detection level during recording of ICM (Not used.)
If the machine (called station) detects dial tone (400 Hz continuously) or busy tone (400 Hz
intermittently) exceeding the detection level specified by these selectors for the period specified by
selectors 1 through 4 on WSW35, then it interprets the calling station as being disconnected. The
machine stops TAD recording and disconnects the line.
- Selectors 4: Duty cycle control of pulsed current for the heat-fuser unit
Setting this selector to "1" activates the duty cycle control that suppresses the rush current.
The duty cycle is 10ms ON and 20ms OFF.
However, the duty cycle control may emit switching noise to the AC line. Depending upon the
codes and regulations in the country, this selector should be set to "0".

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
