Brother MFC-8860DN Servise Manual

App. 4-37 Confidential
WSW33
(Function setting 11)
Selector
No.
Function
Setting and Specifications
1
|
3
Detection threshold level of "no
tone" during recording of ICM
(Not used.)
No. 1 2 3
0 0 0 : -42.5 dBm (A)
0 0 1 : -44.0 dBm (B)
0 1 0 : -45.5 dBm (C)
0 1 1 : -47.0 dBm (D)
1 0 0 : -48.5 dBm (E)
1 0 1 : -50.0 dBm (F)
1 1 0 : -51.5 dBm (G)
1 1 1 : -53.0 dBm (H)
4
5
FAX receiving speed to be kept
within the transmission speed
limit to the PC
(Not used.)
No. 4 5
0 0 : 14,400 bps
0 1 : 12,000 bps
1 0 : 9,600 bps
1 1 : 7,200 bps
6
Report output of polled
transmission requests
0: Yes 1: No
7
8
Comfortable noise level
(Not used.)
No. 7 8
0 0 : OFF
0 1 : Low (A)
1 0 : Medium (B)
1 1 : High (C)
NOTE: Selectors 1 through 3 are applicable to models equipped with internal TADs.
- Selectors 1 through 3: Detection threshold level of "no tone" during recording of ICM (Not used.)
If the tone level during recording of ICM is less than the threshold setting made by these selectors,
the tone is interpreted as "no tone. " When the "no tone" state is kept for the period specified by
selectors 1 through 5 on WSW21, the machine disconnects the line.
- Selectors 4 and 5: FAX receiving speed to be kept within the transmission speed limit to the PC
(Not used.)
To transmit FAX data being received from other machine to the connected PC, you may need to
keep the FAX receiving speed within the transmission speed limit specified for the PC. In an
initial negotiation sequence for transmission, the machine responds to the calling station with the
allowable FAX receiving speed specified by these selectors.
- Selectors 7 and 8: Comfortable noise level (Not used.)
These selectors set the level of noise to be added during playing-back of voice signals recorded
with no-signal compression.
If they are set to "0, 0," no noise will be added.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
