Brother MFC-8860DN Servise Manual

App. 4-38 Confidential
WSW34
(Function setting 12)
Selector
No.
Function
Setting and Specifications
1
|
3
Erasing time length of ICM
tone recorded preceding the
tone detection starting point in
the case of automatic line
disconnection due to no voice
signal received (Not used.)
No. 1 2 3
0 0 0 : 0 sec.
0 0 1 : 1 sec.
0 1 0 : 2 sec.
0 1 1 : 3 sec.
1 0 0 : 4 sec.
1 0 1 : 5 sec.
1 1 0 : 6 sec.
1 1 1 : 7 sec.
4
5
No. of CNG cycles to be
detected
(when the line is connected via
the external telephone in the
external TAD mode or via the
machine in F/T mode)
(Not used.)
No. 4 5
0 0 : 0.5 (A)
0 1 : 1 (B)
1 0 : 1.5 (C)
1 1 : 2 (D)
6
7
Number of DTMF tone signals
for inhibiting the detection of
CNG during external TAD
operation
No. 6 7
0 0 : 3
0 1 : 2
1 0 : 1
1 1 : OFF
8 Not used.
NOTE: Selectors 1 through 5 are applicable to models equipped with built-in TADs.
- Selectors 1 through 3: Erasing time length of ICM tone recorded preceding the tone detection starting
point in the case of automatic line disconnection due to no voice signal received
(Not used.)
If the machine has disconnected the line after detection of disconnection tone in ICM recording, it
erases tone recorded preceding the tone detection starting point for the time length set by these
selectors.
- Selectors 4 and 5: No. of CNG cycles to be detected (when the line is connected via the external
telephone in the external TAD mode or via the machine in F/T mode) (Not used.)
The machine interprets a CNG as an effective signal if it detects a CNG signal by the number of
cycles specified by these selectors when the line is connected via the external telephone in the
external TAD mode or via the machine in F/T mode.
- Selectors 6 and 7: Number of DTMF tone signals for inhibiting the detection of CNG during external
TAD operation
If the machine receives this specified number of DTMF tone signals during external TAD
operation, it will not detect CNG afterwards.
If these selectors are set to "1, 1," the CNG detection will not be inhibited.

Brother MFC-8860DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Grayscale levels	256
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
Paper tray media types	Envelopes, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Windows98(SE)/Me/2000/XP/NT4.0WS Mac OS 9.1-9.2/ OS X 10.2.4 +
Standard interfaces	USB 2.0
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	1104 W
Sustainability certificates	ENERGY STAR
