Page #77 background imageLoading...
Page #77 background image
Dialling and storing numbers
67
8
Storing numbers 8
You can set up your machine to do the
following types of easy dialling: One Touch,
Speed Dial and Groups for Broadcasting
faxes. You can also specify the default
resolution for each One Touch and
Speed Dial number. When you dial a
quick dial number, the LCD shows the name,
if you stored it, or the number. A scan profile
can also be stored along with the fax number.
If you lose electrical power, the quick dial
numbers stored in the memory will not be lost
because they are stored permanently.
A scan profile is the resolution and other scan
settings that you choose when you store a
number. For example, you will be asked to
select Standard, Fine, S.Fine or Photo if you
have selected the Fax/Tel option. Or, you will
be asked to select B/W 200 dpi,
B/W 200x100 dpi, Gray 100dpi, Gray 200dpi,
Gray 300dpi,Color 100 dpi, Color 200 dpi,
Color 300dpi or Color 600 dpi if you selected
the E-Mail option.
Storing a pause 8
Press Redial/Pause to insert a 3.5-second
pause between numbers. You can press
Redial/Pause as many times as needed to
increase the length of the pause.
Storing One Touch Dial
numbers 8
Your machine has 20 One Touch keys where
you can store 40 fax or telephone numbers
for automatic dialling. To access numbers 21
to 40, hold down Shift as you press the
One Touch key.
8
a Press the One Touch key where you
want to store the number.
If a number is not stored there, the LCD
shows Register Now?
Press 1 to choose Yes.
b Press a or b to select Fax/Tel, E-Mail
or IFAX.
Press OK.
c Choose one of the options below:
Enter the number (up to 20
characters) if you selected Fax/Tel.
Press OK.
Enter the E-mail address (up to 60
characters) if you selected E-Mail
or IFAX. Use the chart on
Entering text on page 192 to help
you enter letters.
Press OK.
Note
If you selected E-Mail and save the
E-mail address, you can only use the
E-mail address when you are in Scan
mode. If you selected IFAX and save the
E-mail address, you can only use the
E-mail address when you are in Fax
mode.
d Choose one of the options below:
Enter the name using the dial pad
(up to 15 characters).
Press OK.
Press OK to store the number or
E-mail address without a name.
e If you want to save a fax/scan resolution
along with the number, choose one of
the options below:
If you selected Fax/Tel in step b,
press a or b to select Std, Fine,
S.Fine or Photo.
Press OK.

Table of Contents

Other manuals for Brother MFC-8890DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-8890DW and is the answer not in the manual?

Brother MFC-8890DW Specifications

General IconGeneral
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Economical printingYes
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Scan toE-mail, e-Mail, E-mail Server, File, FTP, Image, OCR, USB
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth24 bit
Output color depth48 bit
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution600 x 2400 DPI
Copier resize25 - 400 %
Maximum copy resolution1200 x 600 DPI
N-in-1 copy function (N=)4, 9, 16, 25
Copy speed (black, normal quality, A4)30 cpm
FaxingMono faxing
Fax memory500 pages
Modem speed33.6 Kbit/s
Fax speed dialing (max numbers)300
Total input capacity250 sheets
Total output capacity150 sheets
Auto document feeder (ADF) input capacity50 sheets
DisplayLCD
Market positioningBusiness
Internal memory64 MB
Sound power level (standby)30 dB
Sound pressure level (printing)56 dB
Dimensions (WxDxH)531 x 451 x 475 mm
All-in-one functionsCopy, Fax, Print, Scan
Maximum internal memory0.576 GB
Color all-in-one functionsScan
Custom media width69.8 - 216 mm
Maximum print size216 x 356 mm
Custom media length116 - 406.4 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 105 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Multi-purpose tray media typesBond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Wi-Fi standards802.11b, 802.11g
Security algorithmsLEAP
Standard interfacesEthernet
USB 2.0 ports quantity1
AC input frequency50 - 60 Hz
Power consumption (standby)85 W
Power consumption (PowerSave)19 W
Power consumption (average operating)680 W
Package weight22100 g
Maximum duty cycle30000 pages per month
Mac operating systems supportedMac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificatesENERGY STAR
