Page #35 background imageLoading...
Page #35 background image
35
For Network Users
Web Based Management
(web browser)
The Brother print server is equipped with a web server
that allows you to monitor its status or change some
of its configuration settings, using HTTP (Hyper Text
Transfer Protocol).
a Open your browser.
b Type “http://machine’s IP address/” into your
browser’s address bar (where “machine’s IP
address” is the IP address of the printer or the
print server name).
For example: http://192.168.1.2/
Print the Network Configuration
List
You can print the Network Configuration List to
confirm the current network settings.
a Turn on the machine and wait until the machine
is in the Ready state.
b Press MENU.
c Press a or b to display Print Reports.
Press Print Reports.
d Press a or b to display Network Config.
Press Network Config.
e Press Black Start or Color Start.
The machine will print the current network
settings.
Restore the network settings to
factory default
To restore all network settings of the internal
Print/Scan server to factory default, please follow the
steps below.
a Make sure the machine is not operating, then
disconnect all the cables from the machine
(except the power cord).
b Press MENU.
c Press a or b to display Network.
Press Network.
d Press a or b to display Network Reset.
Press Network Reset.
e Press Yes.
f Press Yes for 2 seconds.
The machine will restart, re-connect cables
once this is complete.
Note
The default User Name is ‘admin’ and the
default password is access’. You can use a
web browser to change this password.
We recommend Microsoft
®
Internet
Explorer
®
6.0 (or greater) or Firefox 3.0 (or
greater) for Windows
®
and Safari 3.0 (or
greater) for Macintosh. Please also make sure
that JavaScript and cookies are always enabled
in whichever browser you use. To use a web
browser, you will need to know the IP address
of the print server. The IP address of the print
server is listed on the Network Configuration
List.
See Web Based Management in the Network
User's Guide.

Other manuals for Brother MFC-9970CDW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-9970CDW and is the answer not in the manual?

Brother MFC-9970CDW Specifications

General IconGeneral
Weight (imperial)62.8 lbs
Dimensions (WxDxH)490 x 526 x 531 mm
All-in-one functionsCopy, Fax, Print, Scan
Color all-in-one functionscopy, fax, print, scan
Compatible operating systemsWindows, Mac OS
Dimensions (W x D x H) (imperial)19.3 x 20.7 x 20.9 \
Print technologyLaser
Maximum resolution2400 x 600 DPI
Economical printingYes
Print speed (black, normal quality, A4/US Letter)30 ppm
Digital senderNo
Printing colorsBlack, Blue, Red, Yellow
Maximum duty cycle60000 pages per month
Optional functionsFax
Number of print cartridges4
Page description languagesBR-Script 3, PCL 6
Copier resize25 - 400 %
Maximum copy resolution- DPI
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)30 cpm
Scan toE-mail, E-mail Server, File, FTP, Image, OCR, USB
Input color depth48 bit
Image formats supportedBMP, JPG, TIF
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
Total input capacity300 sheets
Total output capacity150 sheets
Maximum print size216 x 356 mm
Paper tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)A4, A5, A6
Maximum ISO A-series paper sizeA4
DisplayLCD
Control typeTouch
Display diagonal5 \
Market positioningBusiness
Direct printing-
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Authentication methodWEP 64/128-b, WPA-PSK (TKIP/AES), WPA2-PSK (AES), 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA, WINS/NetBIOS, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMP, LLTD, SNTP, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Supported network protocols (IPv6)NDP, RA, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMPv6, SNTP, LLTD, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Maximum internal memory512 MB
Sound pressure level (copying)57 dB
AC input voltage110 - 120 V
AC input frequency50 - 60 Hz
Power consumption (standby)1.8 W
Power consumption (average operating)615 W
Package weight34019 g
Operating temperature (T-T)50 - 90.5 °F
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
