Brother MFC-J4335DW User Manual

Home > Security > Use IPsec > Configure IPsec Using Web Based Management
Configure IPsec Using Web Based Management
Related Models: MFC-J4535DW
The IPsec connection conditions comprise two Template types: Address and IPsec. You can configure up to 10
connection conditions.
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Security > IPsec.
Start from , if the navigation menu is not shown on the left side of the screen.
5. Configure the settings.
Option
Description
Status Enable or disable IPsec.
Negotiation Mode Select Negotiation Mode for IKE Phase 1. IKE is a protocol that is
used to exchange encryption keys in order to carry out encrypted
communication using IPsec.
In Main mode, the processing speed is slow, but the security is high.
In Aggressive mode, the processing speed is faster than Main
mode, but the security is lower.
All Non-IPsec Traffic Select the action to be taken for non-IPsec packets.
When using Web Services, you must select Allow for All Non-IPsec
Traffic. If you select Drop, Web Services cannot be used.
Broadcast/Multicast Bypass Select Enabled or Disabled.
Protocol Bypass Select the check box for the option or options you want.
Rules Select the Enabled check box to activate the template. When you
select multiple check boxes, the lower numbered check boxes have
priority if the settings for the selected check boxes conflict.
Click on the corresponding drop-down list to select the Address
Template that is used for the IPsec connection conditions. To add an
Address Template, click Add Template.
Click on the corresponding drop-down list to select the IPsec
Template that is used for the IPsec connection conditions. To add an
IPsec Template, click Add Template.
6. Click Submit.
If the machine must be restarted to register the new settings, the restart confirmation screen will appear.
If there is a blank item in the template you enabled in the Rules table, an error message appears. Confirm
your choices and click Submit again.
Related Information
• Use IPsec
366

Brother MFC-J4335DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Resolution color	1200 x 600 DPI
Maximum resolution	1200 x 4800 DPI
Print resolution black	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	-
Auto document feeder (ADF) input capacity	20 sheets
Copier resize	25 - 400 %
N-in-1 copy function (N=)	2, 4
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Scan to	Cloud, E-mail, File, OCR, PC
Scan drivers	TWAIN
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Image formats supported	JPEG, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (sleep)	1.2 W
Power consumption (average operating)	21 W
Display	LCD
Product color	White
Display diagonal	1.8 \
Market positioning	Home & office
Internal memory	128 MB
Sound pressure level (printing)	53 dB
Sustainability certificates	Blue Angel
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	4
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Envelopes sizes	DL
Paper tray media types	Envelopes, Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Package depth	242 mm
Package width	495 mm
Package height	455 mm
Package weight	10700 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	435 mm
Height	180 mm
Weight	8800 g
