Brother MFC-J4335DW User Manual

Home > Security > Use IPsec > Configure an IPsec Address Template Using Web Based Management
Configure an IPsec Address Template Using Web Based Management
Related Models: MFC-J4535DW
1. Start your web browser.
2. Type "https://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
https://192.168.1.2
3. If required, type the password in the Login field, and then click Login.
The default password to manage this machine’s settings is located on the back of the machine and marked
"Pwd".
4. Go to the navigation menu, and then click Network > Security > IPsec Address Template.
Start from , if the navigation menu is not shown on the left side of the screen.
5. Click the Delete button to delete an Address Template. When an Address Template is in use, it cannot be
deleted.
6. Click the Address Template that you want to create. The IPsec Address Template appears.
7. Configure the settings.
Option
Description
Template Name Type a name for the template (up to 16 characters).
Local IP Address • IP Address
Specify the IP address. Select ALL IPv4 Address, ALL IPv6
Address, ALL Link Local IPv6, or Custom from the drop-down
list.
If you select Custom from the drop-down list, type the IP address
(IPv4 or IPv6) in the text box.
• IP Address Range
Type the starting and ending IP addresses for the IP address
range in the text boxes. If the starting and ending IP addresses
are not standardized to IPv4 or IPv6, or the ending IP address is
smaller than the starting address, an error will occur.
• IP Address / Prefix
Specify the IP address using CIDR notation.
For example: 192.168.1.1/24
Because the prefix is specified in the form of a 24-bit subnet mask
(255.255.255.0) for 192.168.1.1, the addresses 192.168.1.xxx are
valid.
Remote IP Address
• Any
If you select Any, all IP addresses are enabled.
• IP Address
Type the specified IP address (IPv4 or IPv6) in the text box.
• IP Address Range
Type the starting and ending IP addresses for the IP address
range. If the starting and ending IP addresses are not
standardized to IPv4 or IPv6, or the ending IP address is smaller
than the starting address, an error will occur.
• IP Address / Prefix
Specify the IP address using CIDR notation.
368

Brother MFC-J4335DW Specifications

General

Duplex printing	Yes
Print technology	Inkjet
Resolution color	1200 x 600 DPI
Maximum resolution	1200 x 4800 DPI
Print resolution black	1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	- ppm
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service
Total input capacity	150 sheets
Total output capacity	100 sheets
Total number of input trays	-
Auto document feeder (ADF) input capacity	20 sheets
Copier resize	25 - 400 %
N-in-1 copy function (N=)	2, 4
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Scan to	Cloud, E-mail, File, OCR, PC
Scan drivers	TWAIN
Scanner type	Flatbed & ADF scanner
Scan speed (black)	17 ppm
Scan speed (color)	7 ppm
Image formats supported	JPEG, JPG
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (sleep)	1.2 W
Power consumption (average operating)	21 W
Display	LCD
Product color	White
Display diagonal	1.8 \
Market positioning	Home & office
Internal memory	128 MB
Sound pressure level (printing)	53 dB
Sustainability certificates	Blue Angel
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Print
Maximum duty cycle	30000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	4
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Envelopes sizes	DL
Paper tray media types	Envelopes, Glossy paper, Plain paper, Recycled paper
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Package depth	242 mm
Package width	495 mm
Package height	455 mm
Package weight	10700 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	343 mm
Width	435 mm
Height	180 mm
Weight	8800 g
