Brother MFC-J4410DW Quick Start Guide

20
For Wireless Network Users
19
Setup using the
installation CD-ROM and
a USB cable (Windows
®
and Macintosh)
a Put the supplied installation CD-ROM into your
CD-ROM drive. Follow the on-screen
instructions.
b The CD-ROM Top menu will appear.
Click Install MFL-Pro Suite and click Yes if
you accept the license agreements. Follow the
on-screen instructions.
c Choose Wireless Network Connection, and
then click Next.
d When Firewall/AntiVirus detected screen
appears, choose Change the Firewall port
settings to enable network connection and
continue with the installation.
(Recommended) and click Next.
If you are using a firewall other than the
Windows
®
Firewall, see the instructions
provided with your firewall software for
information on how to add the following
network ports.
 For network scanning, add UDP port 54925.
 For network PC-Fax receiving, add UDP port
54926.
 If you still have trouble with your network
connection, add UDP ports 137 and 161.
e Choose Yes, I have a USB cable to use for
installation. and then click Next.
f Temporarily connect the USB cable (not
included) directly to the computer and the
machine.
If the confirmation screen appears, check the
box and click Next, go to g.
Otherwise, go to h.
g When the following screen appears, check Yes
if you want to connect to the listed SSID. Click
Next and go to j.
h When the following screen appears, the wizard
will search for wireless networks available to
your machine. Choose the SSID that you wrote
down for your network on page 18, and then
click Next.
These steps are for a Windows
®
installation.
For Macintosh installation, insert the
installation CD-ROM into your CD-ROM drive
and double-click Start Here OSX to install.
Select Wireless installation and follow the
Wireless Device Setup instructions on your
computer screen.
NOTE
• For instructions on connecting the USB cable
to the USB port of your machine, see Connect
the USB cable on page 10.
• If the Important Notice appears, check the
box after you confirm the SSID and Network
Key, and then click Next.
NOTE
• If a list of SSIDs is not displayed, make sure
your access point is on and set to broadcast the
SSID. Make sure the machine and the access
point are within communication range, then
click Refresh.
• If your access point is set to not broadcast the
SSID you can manually add it by clicking the
Advanced button. Follow the on-screen
instructions for entering the Name (SSID), and
then click Next.

Brother MFC-J4410DW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	18 ipm
Print speed (ISO/IEC 24734) color	16 ipm
Duplex print speed (ISO/IEC 24734) mono	6 ipm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	25 ppm
All-in-one functions	Copy, Fax, Print, Scan
Networking standards	IEEE 802.3, IEEE 802.3u
Color all-in-one functions	copy, fax, print, scan
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 1000 pages per month
Number of print cartridges	4
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	20 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	2400 x 2400 DPI
Faxing	Color faxing
Fax memory	200 pages
Modem speed	336 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax resolution (black)	203 x 392 DPI
Fax transmission speed	3.37 sec/page
Fax speed dialing (max numbers)	100
Paper input type	Paper tray
Total input capacity	150 sheets
Total output capacity	50 sheets
Total number of input trays	-
Auto document feeder (ADF) input capacity	20 sheets
Photo paper sizes	9x13, 10x15, 13x18 cm
Custom media width	148 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Paper tray media types	Envelopes, Glossy paper, Photo paper, Plain paper, Transparencies
Paper tray media weight	64 - 220 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
Photo paper sizes (imperial)	4x6, 5x7, 5x8, 3.5x5 \
Borderless printing media sizes	4x6, 5x7, A3, A4, A6, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	64 - 105 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, Ivory
Display diagonal	1.8 \
Market positioning	Home & office
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Compatible memory cards	Memory Stick (MS), MMC, MMC+, MS Duo, MS PRO, SD, SDHC
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.4 W
Power consumption (standby)	5.5 W
Power consumption (PowerSave)	1.5 W
Power consumption (average operating)	21 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	266 mm
Package width	564 mm
Package height	416 mm
Package weight	11500 g
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)

Weight and Dimensions

Depth	290 mm
Width	480 mm
Height	186 mm
