Brother MFC-J480DW User Manual

Home > Fax > Telephone Services and External Devices > External TAD (Telephone Answering Device)
External TAD (Telephone Answering Device)
You can connect an external Telephone Answering Device (TAD) to the same line as your machine. When the
TAD answers a call, your machine will “listen” for the CNG (fax calling) tones sent by a sending fax machine. If it
hears them it will take over the call and receive the fax. If it does not hear them, it will let your TAD take a voice
message and the LCD will show [Telephone].
The external TAD must answer within four rings (we recommend setting it to two rings). This is because your
machine cannot hear the CNG tones until the external TAD has picked up the call. The sending machine will
send CNG tones for only eight to ten seconds longer. We do not recommend using the toll saver feature on your
external TAD if it needs more than four rings to activate it.
Unless you are using Distinctive Ring, the TAD must be connected to the EXT. jack of the machine.
• If you subscribe to your telephone company’s Distinctive Ring service:
You may connect an external TAD to a separate wall jack only if you subscribe to your telephone company’s
Distinctive Ring service, have registered the distinctive ring pattern on your machine, and use that number as
a fax number. The recommended setting is at least four rings on the external TAD when you have the
telephone company’s Distinctive Ring service. You cannot use the Toll Saver setting.
• If You Do Not Subscribe to the Distinctive Ring Service:
You must plug your TAD into the EXT. jack of your machine. If your TAD is plugged into a wall jack, both your
machine and the TAD will try to control the telephone line. (See the illustration.)
1
1
2 Protective Cap
1 TAD
2
IMPORTANT
DO NOT connect a TAD elsewhere on the same telephone line.
If you have problems receiving faxes, reduce the Ring Delay setting on your external TAD.
Related Information
• Telephone Services and External Devices
• Connect an External TAD
• Record an Outgoing Message (OGM) on the External TAD
• Multi-line Connections (PBX)
308

Brother MFC-J480DW Specifications

General

Display	LCD
Control type	Touch
Product color	Black
Display diagonal	1.8 \
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.0 Cheetah, Mac OS X 10.9 Mavericks
Other operating systems supported	Android, iOS, Windows Phone
Server operating systems supported	Windows Server 2012 R2 x64, Windows Server 2003, Windows Server 2008 R2 x64, Windows Server 2012 x64, Windows Server 2008 x64, Windows Server 2003 x64, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 8, Windows Vista Home Premium, Windows 10 Education, Windows 7 Enterprise x64, Windows 8 Enterprise, Windows Vista Home Premium x64, Windows 10 Education x64, Windows 7 Home Basic, Windows 8 Enterprise x64, Windows Vista Ultimate, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 8 Pro, Windows Vista Ultimate x64, Windows 10 Enterprise x64, Windows 7 Home Premium, Windows 8 Pro x64, Windows XP Home, Windows 10 Home, Windows 7 Home Premium x64, Windows 8 x64, Windows XP Home x64, Windows 10 Home x64, Windows 7 Professional, Windows 8.1, Windows Vista Business, Windows XP Professional, Windows 10 Pro, Windows 7 Professional x64, Windows 8.1 Enterprise, Windows Vista Business x64, Windows XP Professional x64, Windows 10 Pro x64, Windows 7 Starter, Windows 8.1 Enterprise x64, Windows Vista Enterprise, Windows 7 Starter x64, Windows 8.1 Pro, Windows Vista Enterprise x64, Windows 7 Ultimate, Windows 8.1 Pro x64, Windows Vista Home Basic, Windows 7 Ultimate x64, Windows 8.1 x64, Windows Vista Home Basic x64
Sustainability certificates	Nordic Swan Ecolabel, ENERGY STAR
Ethernet LAN	No
Wi-Fi standards	802.11g, 802.11b, Wi-Fi 4 (802.11n)
Security algorithms	WPA2-AES, SSID, 64-bit WEP, WPA2-PSK, 128-bit WEP, WPS, WPA-AES, WPA-PSK, WPA-TKIP
Online services supported	Box, Facebook, OneDrive, Dropbox, Flickr, OneNote, Evernote, Google Drive, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service, Google Cloud Print
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	11 ipm
Print speed (ISO/IEC 24734) color	6 ipm
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	23 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 2400 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	6 cpm
Copy speed (color, normal quality, A4)	3 cpm
Scan to	Image, Fax, E-mail, File, OCR
Scan drivers	ICA, TWAIN, WIA
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Faxing	Color faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Fax resolution (black)	203 x 203 DPI
Fax speed dialing (max numbers)	40
Printing colors	Black, Cyan, Magenta, Yellow
Number of print cartridges	4
Envelopes sizes	C5, Com-10, DL, Monarch
Paper tray media types	Glossy paper, Plain paper, Coated paper, Recycled paper
Non-ISO print media sizes	2L, Executive (184 x 267mm), Letter (media size), Index card, L
ISO A-series sizes (A0...A9)	A5, A6, A4
Borderless printing media sizes	2L, 10x15, Letter, A4, Index card, L, A6
Maximum ISO A-series paper size	A4
Direct printing	-
Standard interfaces	USB 2.0, Wireless LAN
Package depth	249 mm
Package width	477 mm
Package height	456 mm
Package weight	10100 g
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (average operating)	19 W
Noise level	50 dB
Bundled software	Brother ControlCenter 2 Brother ControlCenter 4 Nuance Paperport 14 SE Brother MFL-Pro Suite
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Internal memory	128 MB
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	341 mm
Width	400 mm
Height	172 mm
Weight	8300 g
