Home > Routine Maintenance > Clean Your Brother Machine > Clean the Print Head from Your Computer
(Windows
®
)
Clean the Print Head from Your Computer (Windows
®
)
To maintain good print quality, the machine automatically cleans the print head when needed. If there is a print
quality problem, start the cleaning process manually.
1. Do one of the following:
For Windows Server
®
2008
Click
(Start) > Control Panel > Hardware and Sound > Printers.
For Windows
®
7 and Windows Server
®
2008 R2
Click
(Start) > Devices and Printers.
For Windows
®
8
Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings,
and then click Control Panel. In the Hardware and Sound group, click View devices and printers.
For Windows Server
®
2012
Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings,
and then click Control Panel. In the Hardware group, click View devices and printers.
For Windows Server
®
2012 R2
Click Control Panel on the Start screen. In the Hardware group, click View devices and printers.
For Windows
®
10 and Windows Server
®
2016
Click
> Windows System > Control Panel. In the Hardware and Sound group, click View devices
and printers.
2. Right-click the Brother MFC-XXXX Printer icon (where XXXX is your model name), and then select Printing
preferences. If printer driver options appear, select your printer driver.
The printer driver dialog box appears.
3. Click the Maintenance tab.
4. Select one of the following options:
Option Description
Check Print Quality... Use to print the test page and check the print quality.
Print Head Cleaning... Use to start the cleaning process manually. Select if a line or blank spaces
appear in text or graphics on the test page.
5. Do one of the following:
If you selected the Check Print Quality... option, click Start.
The machine prints the test page.
If you selected the Print Head Cleaning... option, select the Black only, Color only, or All option for the
cleaning type, and then click Next.
6. Select the Normal, Strong, or Strongest option for the cleaning strength, and then click Next.
7. Click Start.
The machine starts cleaning.
Related Information
Clean Your Brother Machine
Paper Handling and Printing Problems
515

Table of Contents

Other manuals for Brother MFC-J491DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J491DW and is the answer not in the manual?

Brother MFC-J491DW Specifications

General IconGeneral
DisplayLCD
Product colorBlack
Built-in displayYes
Display diagonal1.77 \
Market positioningHome & office
Internal memory128 MB
Card reader integratedNo
Sound pressure level (copying)50 dB
Print technologyInkjet
Maximum resolution1200 x 6000 DPI
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono12 ipm
Print speed (ISO/IEC 24734) color6 ipm
Time to first page (black, normal)8 s
Duplex print speed (ISO/IEC 24734) mono3 ipm
Duplex print speed (ISO/IEC 24734) color1.7 ipm
Print speed (black, normal quality, A4/US Letter)27 ppm
Print speed (color, normal quality, A4/US Letter)10 ppm
Standard interfacesUSB 2.0, Wireless LAN
USB 2.0 ports quantity1
Copier resize25 - 400 %
Maximum copy resolution1200 x 600 DPI
Package depth249 mm
Package width447 mm
Package height457 mm
Package weight10100 g
Power consumption (off)0.2 W
Power consumption (sleep)1 W
Power consumption (standby)3.5 W
Power consumption (printing)16 W
Power consumption (average operating)- W
Sustainability certificatesNordic Swan Ecolabel, ENERGY STAR
FaxingMono faxing
Fax memory170 pages
Modem speed14.4 Kbit/s
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Mobile printing technologiesApple AirPrint, Mopria Print Service
Paper input typePaper tray
Total input capacity100 sheets
Total output capacity50 sheets
Auto document feeder (ADF) input capacity20 sheets
Paper tray media typesPlain paper
Borderless printing media sizesA4
Scan toE-mail, File, Image, OCR
Scanner typeFlatbed & ADF scanner
Input color depth30 bit
Output color depth24 bit
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
Digital sender-
Maximum duty cycle- pages per month
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth341 mm
Width400 mm
Height172 mm
