Brother MFC-J5730DW Service Manual

Confidential
2-11
Error
Code
Contents
Refer to
page:
2200 Black ink cartridge side IC chip relation defective
- It is judged as incompatible ink cartridge is loaded.
2-28
2201 Yellow ink cartridge side IC chip relation defective
- It is judged as incompatible ink cartridge is loaded.
2-28
2202 Cyan ink cartridge side IC chip relation defective
- It is judged as incompatible ink cartridge is loaded.
2-28
2203 Magenta ink cartridge side IC chip relation defective
- It is judged as incompatible ink cartridge is loaded.
2-28
2300 Black ink cartridge side IC chip relation defective
- It is judged as optional ink cartridge has been loaded before the initial
installation is started.
2-28
2301 Yellow ink cartridge side IC chip relation defective
- It is judged as optional ink cartridge has been loaded before the initial
installation is started.
2-28
2302 Cyan ink cartridge side IC chip relation defective
- It is judged as optional ink cartridge has been loaded before the initial
installation is started.
2-28
2303 Magenta ink cartridge side IC chip relation defective
- It is judged as optional ink cartridge has been loaded before the initial
installation is started.
2-28
2400 Black ink cartridge side IC chip relation defective
- Identification no match
- Judging as incompatible ink cartridge
2-29
2401 Yellow ink cartridge side IC chip relation defective
- Identification no match
- Judging as incompatible ink cartridge
2-29
2402 Cyan ink cartridge side IC chip relation defective
- Identification no match
- Judging as incompatible ink cartridge
2-29
2403 Magenta ink cartridge side IC chip relation defective
- Identification no match
- Judging as incompatible ink cartridge
2-29
2500
Cannot communicate with b lack ink cartridge IC chip (ink cartridge side.) 2-29
2501
Cannot communicate with y ellow ink cartridge IC chip (ink cartridge side.) 2-29
2502
Cannot communicate with cyan ink cartridge IC chip (ink cartridge side.) 2-29
2503
Cannot communicate with m agenta ink cartridge IC chip (ink cartridge side.) 2-29
2600 Black ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for
specified times.
2-30
2601 Yellow ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for
specified times.
2-30
2602 Cyan ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for
specified times.
2-30
2603 Magenta ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for
specified times.
2-30
