Brother MFC-J5730DW Service Manual

Confidential
2-13
Error
Code
Contents
Refer to
page:
5D00 Excessive current protection activated for the head driver IC during purge
cam operation.
2-38
5E00 Excessive current protection activated for the head driver IC during pump
operation.
2-38
6700 T1 detection sensor detects no paper tray #1 state. 2-38
6701 T2 detection sensor detects no paper tray #2 state. 2-39
6F00 ASF motor cannot stop. 2-39
6F01 ASF encoder sensor cannot detect rotation of the ASF motor. 2-39
7000 Failed to detect ON/OFF of the purge cam. 2-40
7200
Failed to detect the origin of the purge cam. 2-40
7500 Cap cam cannot shift to head capping position. 2-40
7600 Cap cam cannot shift to head uncapping position. 2-40
7A00 Purge cam rotation error (capping CW) 2-40
7D00 Current protection activated for the cap driver IC. 2-40
7E00 Head property information not input. 2-40
8000 Recording paper size error (during FAX/list printing) (Only the models
with single tray) The registration sensor and paper width sensor detect
that the size of the loaded recording paper does not match the recording
paper size setting.
2-41
8001 Paper tray #1 recording paper size error (during FAX/list printing) (Only
the models with multiple trays) The registration sensor and paper width
sensor detect that the size of the loaded recording paper does not match
the recording paper size setting.
2-41
8002 Paper tray #2 recording paper size error (during FAX/list printing) (Only
the models with multiple trays) The registration sensor and paper width
sensor detect that the size of the loaded recording paper does not match
the recording paper size setting.
2-41
8004 MP tray recording paper size error (during FAX/list printing) (Only the
models with multiple trays) The registration sensor and paper width
sensor detect that the size of the loaded recording paper does not match
the recording paper size setting.
2-41
8101 Recording paper size error (during FAX/list printing) (Only the models
with single tray) The registration sensor and paper width sensor detect
recording paper smaller than the setting size.
2-41
8102 Recording paper size error (during PC printing) (Only the models with
single tray) The registration sensor and paper width sensor detect
recording paper smaller than the setting size.
2-41
8103 Recording paper size error (during copy printing) (Only the models with
single tray) The registration sensor and paper width sensor detect
recording paper smaller than the setting size.
2-41
8104 Paper tray #1 recording paper size error (during FAX/list printing) (Only
the models with multiple trays) The registration sensor and paper width
sensor detect recording paper smaller than the setting size.
2-41
8105 Paper tray #2 recording paper size error (during FAX/list printing) (Only
the models with multiple trays) The registration sensor and paper width
sensor detect recording paper smaller than the setting size.
2-41
