Page #23 background imageLoading...
Page #23 background image
1-1
Confidential
CHAPTER 1 SPECIFICATIONS
This chapter lists the specifications of each model, which enables you to make a comparison
of different models.
1GENERAL
1.1 General
1.2 Media Specification
*1
Only for Taiwan/China
*2
Only for China
Model
HL-J6000DW/
J6100DW
HL-T4000DW
MFC-J3530DW/J3930DW/J6530DW/J6535DW/J6545DW/
J6730DW/J6930DW/J6935DW/J6945DW/J6947DW
MFC-
T4500DW
Print Head
BHS13plus
Head
BK/C/M/Y:
420/420/420/
420 nozzles
BHM17HT
Head
BK/C/M/Y:
420/420/420/
420 nozzles
BHS13plus Head
BK/C/M/Y: 420/420/420/420 nozzles
BHM17HT
Head
BK/C/M/Y:
420/420/420/
420 nozzles
Minimum
Droplet Size
BK: 4 pl
CMY: 1.5 pl
BK: 3 pl
CMY: 1.5 pl
BK: 4 pl
CMY: 1.5 pl
BK: 3 pl
CMY: 1.5 pl
Scanning
Method
N/A CIS
CPU Speed 576 MHz
Backup
Clock
Yes (Up to 1 hour)
Model HL-J6000DW HL-J6100DW HL-T4000DW
Media
Sizes
Standard Tray
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR, B4 (JIS)
*1
, LGL, Folio, A5, B6 (JIS)
*1
, A6, Photo
(102 x 152 mm/4 x 6"), Index card (127 x 203 mm/5 x 8"), Photo-L (89 x
127 mm/3.5 x 5"), Photo-2L (127 x 178 mm/5 x 7"), C5, Com-10, DL
Envelope, Monarch, Mexico Legal, India Legal, 16K (195 x 270 mm)
*2
Lower Tray
<Landscape> A4, LTR
<Portrait> A3, LGR, LGL, Folio, Mexico Legal,
India Legal
N/A
3rd Tray
N/A
<Landscape> A4, LTR
<Portrait> A3, LGR,
LGL, Folio, Mexico
Legal, India Legal
N/A
Manual Feed Slot
N/A
MP Tray
<Landscape> A4, LTR, EXE, B5 (JIS)
*1
<Portrait> A3, LGR, B4 (JIS)
*1
, LGL, Folio, A5, B6 (JIS)
*1
, A6, Photo
(102 x 152 mm/4 x 6"), Index card (127 x 203 mm/5 x 8"), Photo-L (89 x
127 mm/3.5 x 5"), Photo-2L (127 x 178 mm/5 x 7"), Com-10, DL
Envelope, Monarch, C5, Mexico Legal, India Legal, 16K (195 x 270
mm)
*2
Duplex Print
<PC Print> A3, LGR, B4(JIS)
*1
, LGL, Folio, A4, LTR, EXE, A5,
B5(JIS)
*1
, B6(JIS)
*1
, Mexico Legal, India Legal, 16K (195x270mm)
*2
ADF (width/length) N/A
Scanner Glass
(width/length)
N/A

Table of Contents

Other manuals for Brother MFC-T4500DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-T4500DW and is the answer not in the manual?

Brother MFC-T4500DW Specifications

General IconGeneral
Copier resize25 - 400 %
N-in-1 copy functionYes
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A3)15 cpm
Copy speed (color, normal quality, A3)11 cpm
FaxingMono faxing
Fax memory180 pages
Modem speed33.6 Kbit/s
Fax transmission speed3 sec/page
Fax speed dialing (max numbers)2
Standard interfacesEthernet, USB, Wireless LAN
Scan toE-mail, FTP, File, HTTP, Image, OCR, USB
Scanner typeFlatbed scanner
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
DisplayTFT
Product colorBlack
Display diagonal2.7 \
Market positioningHome & office
Print technologyInkjet
Maximum resolution1200 x 4800 DPI
Print speed (black, normal quality, A3)22 ppm
Print speed (color, normal quality, A3)20 ppm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Security algorithmsSMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Server, SNMPv1/v2c/v3, TFTP server, SMTP Client, ICMP, Web Services (Print/Scan), CIFS Client, SNTP Client, LDAP, HTTP Server
Supported network protocols (IPv6)NDP, RA, mDNS, LLMNR Responder, DNS Resolver, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Server, SNMPv1/v2c/v3 , TFTP server, Web Services (Print/Scan), SMTP Client, CIFS Client, SNTP Client, LDAP, ICMPv6, HTTP Server
Printer managementBRAdmin Light
Internal memory128 MB
Card reader integratedNo
Sound pressure level (printing)50 dB
Power consumption (off)0.04 W
Power consumption (ready)6 W
Power consumption (sleep)1.5 W
Power consumption (copying)28 W
Power consumption (average operating)- W
Sustainability certificatesENERGY STAR
Mac operating systems supportedMac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Envelopes sizesCom-10, DL, Monarch
Photo paper sizes9x13 cm
Non-ISO print media sizesFolio (media size), Index card, Legal (media size)
ISO A-series sizes (A0...A9)A3, A5
ISO C-series sizes (C0...C9)C5
JIS B-series sizes (B0...B9)B5, B6
Photo paper sizes (imperial)3.5x5, 4x6, 5x7 \
Maximum ISO A-series paper sizeA3
Paper input typePaper tray
Total output capacity250 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Weight and Dimensions IconWeight and Dimensions
Depth477 mm
Width575 mm
Height310 mm
