Brother MFC-T4500DW Service Manual

Confidential
2-19
Error Message State
Error
Code
Reference
No Cartridge No ink cartridge loaded.
Detected by the ink cartridge detection sensor.
2A00
2A01
2A02
2A03
2-32
Cannot communicate with ink cartridge IC chip
(ink cartridge side.)
2500
2501
2502
2503
2-30
No Device When configuring the Wi-Fi Direct network, the
machine cannot find the mobile device.
--- 4.5.1
No File The external memory in the media drive does not
contain a .JPGfile.
--- 4.10.3
No Paper Fed
Repetitive No Paper Fed
It is detected that there is no recording paper in
the valid trays for printing.
--- 4.2.1
4.2.2
4.2.3
No Response/Busy The dialled number does not answer or is busy. --- 4.9.3
Out of Fax Memory
Out of Memory
The memory becomes full. --- 4.10.4
Paper size Mismatch
Wrong Tray Settings
The size of the paper loaded in the tray does not
match the specified print size.
8101
8102
8103
8104
8105
8107
8108
8109
810B
810C
810D
810F
8110
8111
8112
8113
8114
8115
8120
2-43
2-44
2-45
2-46
Paper Tray not detected
Paper Tray #1 not detected
Paper Tray #2 not detected
Paper Tray #3 not detected
Paper tray detection sensor detects no paper tray
state.
6700
6701
6702
2-41
Replace Ink
Refill Ink
Ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor,
ink discharged for specified times.
The amount of remaining ink in one or more of the ink
tanks is low.
2600
2601
2602
2603
2-31
Sending Error
Wrong Document Size Settings
The size of the document does not match the
specified scanning document size.
The maximum number of
devices are already connected
using Wi-Fi Direct.
The maximum number of mobile devices are already
connected to the Wi-Fi Direct network when the
machine is the Group Owner (G/O).
--- 4.5.1

Brother MFC-T4500DW Specifications

General

Copier resize	25 - 400 %
N-in-1 copy function	Yes
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A3)	15 cpm
Copy speed (color, normal quality, A3)	11 cpm
Faxing	Mono faxing
Fax memory	180 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Fax speed dialing (max numbers)	2
Standard interfaces	Ethernet, USB, Wireless LAN
Scan to	E-mail, FTP, File, HTTP, Image, OCR, USB
Scanner type	Flatbed scanner
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Display	TFT
Product color	Black
Display diagonal	2.7 \
Market positioning	Home & office
Print technology	Inkjet
Maximum resolution	1200 x 4800 DPI
Print speed (black, normal quality, A3)	22 ppm
Print speed (color, normal quality, A3)	20 ppm
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	SMTP-AUTH, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Server, SNMPv1/v2c/v3, TFTP server, SMTP Client, ICMP, Web Services (Print/Scan), CIFS Client, SNTP Client, LDAP, HTTP Server
Supported network protocols (IPv6)	NDP, RA, mDNS, LLMNR Responder, DNS Resolver, LPR/LPD, Custom Raw Port/Port9100, IPP, FTP Server, SNMPv1/v2c/v3 , TFTP server, Web Services (Print/Scan), SMTP Client, CIFS Client, SNTP Client, LDAP, ICMPv6, HTTP Server
Printer management	BRAdmin Light
Internal memory	128 MB
Card reader integrated	No
Sound pressure level (printing)	50 dB
Power consumption (off)	0.04 W
Power consumption (ready)	6 W
Power consumption (sleep)	1.5 W
Power consumption (copying)	28 W
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Envelopes sizes	Com-10, DL, Monarch
Photo paper sizes	9x13 cm
Non-ISO print media sizes	Folio (media size), Index card, Legal (media size)
ISO A-series sizes (A0...A9)	A3, A5
ISO C-series sizes (C0...C9)	C5
JIS B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	3.5x5, 4x6, 5x7 \
Maximum ISO A-series paper size	A3
Paper input type	Paper tray
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets

Weight and Dimensions

Depth	477 mm
Width	575 mm
Height	310 mm
