3-6
Confidential
4 SCREW TORQUE LIST
Note Check the shape of screw with SCREW CATALOGUE in the previous page.
*1 For models with ADF *2 Touch panel models
*3 MFC model only *4 200V model only
Location of Screw Screw Type Q’ty
Tightening Torque
N • m (kgf • cm)
ADF FG wire*1/Document scanner
FG wire (Together with ADF FG wire)
TAPTITE CUP S M3x6 1 0.35±0.05 (3.5±0.5)
Document scanner bottom cover TAPTITE CUP B M3x10 6 0.40±0.05 (4±0.5)
ADF top cover rear TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
Upper document chute TAPTITE CUP B M3x10 2 0.50±0.10 (5±1)
ADF back cover TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
Panel front cover TAPTITE CUP B M3x10 3 0.40±0.10 (4±1)
FG wire*2 TAPTITE CUP S M3x6 1 0.35±0.05 (3.5±0.5)
Upper cover TAPTITE BIND B M4x12 4 0.85±0.05 (8.5±0.5)
TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
Main PCB shield TAPTITE CUP S M3x6 2 0.35±0.05 (3.5±0.5)
Main PCB ASSY TAPTITE CUP S M3x6 1 0.35±0.05 (3.5±0.5)
Main PCB frame TAPTITE CUP S M3x6 1 0.35±0.05 (3.5±0.5)
MJ upper frame*3 TAPTITE CUP B M3x10 2 0.40±0.10 (4±1)
MJ PCB ASSY*3 TAPTITE CUP S M3x6 2 0.35±0.05 (3.5±0.5)
Power supply unit TAPTITE CUP B M3x10 1 0.40±0.10 (4±1)
TAPTITE CUP S M3x6 1 0.35±0.05 (3.5±0.5)
Power cord FG wire*4
SCREW PAN (WASHER)
M4x8 DB
1 0.45±0.05 (4.5±0.5)
Power supply PCB TAPTITE CUP S M3x6 3 0.45±0.05 (4.5±0.5)
PF encoder sensor PCB ASSY SCREW BIND M2x10 1 0.15±0.05 (1.5±0.5)
CR frame TAPTITE CUP B M3x10 2 0.60±0.10 (6±1)
Carriage motor SCREW BIND M3x6 2 0.75±0.10 (7.5±1)
CR guide rail TAPTITE CUP B M3x10 2 0.60±0.10 (6±1)
SCREW BIND M3x6 2 0.63±0.07 (6.3±0.7)
Paper feed motor SCREW BIND M2.6x4 2 0.44±0.06 (4.4±0.6)
Side frame L TAPTITE CUP B M3x10 4 0.50±0.10 (5±1)
Registration sensor PCB ASSY TAPTITE BIND B M2.6x8 1 0.35±0.05 (3.5±0.5)
