3-84
Confidential
9.21 Paper Feed Motor
(1) Remove the two screws of the TAPTITE CUP B M3x10 and two screws of the
SCREW BIND M3x6, remove the two CR guide rail springs, and then remove the CR
guide rail.
(3_062L)
