53
Ch. 4 Machine Adjustments
Machine Adjustments
To change the HEAD ADJUSTMENT setting:
This function allows you to shift the printing up
or down within the tape.
1 Hold down d and press A.
2 Rotate r until HEAD ADJUSTMENT is dis-
played, and then press r (OR press j or
k until HEAD ADJUSTMENT is displayed).
3 Rotate r (or press m or g) until the
desired setting is displayed.
4 Press r (or press n) to apply the setting.
To change the HALF CUTTER setting:
This function allows you to adjust how deep a
half cut is cut with laminated tape, for example, if
the tape is cut too much or not enough. Nor-
mally, it is only necessary to change the setting by
one. If the half cut is still either too deep or not
deep enough, change the setting by one again.
1 Hold down d and press A.
2 Rotate r until HALF CUTTER is displayed,
and then press r (OR press j or k until
HALF CUTTER is displayed).
3 Rotate r (or press m or g) until the
desired setting is displayed.
4 Press r (or press n) to apply the setting.
NOTE
This function does not adjust printing on 36-mm-
wide tape.
NOTE
This step may be skipped if settings for several
Setup functions are being applied at the same time.
NOTE
☞ To return the function to its default setting (0),
press the space bar.
☞ To shift the printing down, select a lower value.
To shift the printing up, select a higher value.
NOTE
If r is used to select the settings, only one function
can be set at a time. To apply several Setup settings
at the same time, press j or k to select the func-
tion, and then press m or g to select the desired
setting. Press n only after the necessary functions
have been set.
Length Margin Font Width Size
1 2 3 4 5 6 7 8 9 A B C D E F K
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
R
R
R
R
R
R
G
H
I
J
03/05
HEAD ADJUSTMENT
00
AUTO 0.4 HELSINKI A AUTO
L
M
NO
NOTE
If the tape is still not cut correctly even after this set-
ting has been continuously adjusted, the cutter may
be dull. Contact your service representative.
NOTE
This step may be skipped if settings for several
Setup functions are being applied at the same time.
NOTE
☞ To cut less deep, select a lower value. To cut
deeper, select a higher value.
☞ Adjust the setting in small steps.
☞ To return the function to its default setting (0),
press the space bar.
NOTE
If r is used to select the settings, only one function
can be set at a time. To apply several Setup settings
at the same time, press j or k to select the func-
tion, and then press m or g to select the desired
setting. Press n only after the necessary functions
have been set.
Length Margin Font Width Size
1 2 3 4 5 6 7 8 9 A B C D E F K
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
R
R
R
R
R
R
G
H
I
J
04/05
HALF CUTTER
00±3
AUTO 0.4 HELSINKI A AUTO
L
M
NO
