Brother P-TOUCH CUBE PT-P300BT User Manual

Over time, the Cutter Blade may become blunt from repetitive use. If the Cutter does not
cut tape cleanly, rotate and reset the Cutter Board as shown in the illustration (1).
If you still have difficulties, replace the Cutter Unit (2).
Contact you local authorized Brother reseller or visit brothermall.com
to order item TC4, the
Cutter Unit.
XReplacing the Cutter Unit
5HPRYHWKHWZRVHFWLRQVRIWKH&XWWHU8QLW(green) in the direction of the arrows shown
in the illustration (2).
2. Install the new Cutter Unit. Unit by pressing the two new pieces down until they lock into
place.
Check that the package contains the following before using the label printer. If any item is
missing or damaged, contact your Brother reseller.
Accessories
Unpack the PT-P300BT
PT-P300BT Starter Tape Cassette
Cutter Board
Cutter's Edge
1
2

Brother P-TOUCH CUBE PT-P300BT Specifications

General

Model	PT-P300BT
Print Technology	Thermal Transfer
Maximum Resolution	180 dpi
Maximum Print Speed	20 mm/sec
Connectivity	Bluetooth
Mobile Device Compatibility	iOS, Android
Compatible Tape	Brother TZe tapes
Cutter	Manual
Max. Label Length	300 mm
Tape Width	3.5mm, 6mm, 9mm, 12mm
Power Source	6 AAA Batteries or AC Adapter (not included)
Mobile App	P-Touch Design&Print
Weight	380 g
Dimensions	115 mm x 115 mm x 61 mm
