ELECTRONIC LABELING SYSTEM
GETTING STARTED
Power Supply and Tape Cassette
Open the cassette cover by pressing the above
indicated area at the top end of the label maker.
• Make sure you turn off the power when replacing
batteries or tape cassettes.
Insert a tape cassette, making sure it snaps
into place.
• Make sure the end of the tape feeds under the tape guides.
• Use Genuine Brother P-touch TZe tapes with this label maker.
Print head
Tape cutter leverCassette cover
Tape exit slot
Toothed Wheel
Cutter's edge
End of tape
Tape guides
With your new Brother P-touch label maker, you can create a wide variety of custom, self-adhesive labels. This label
maker uses Brother "TZe" tapes from 0.13" (3.5mm) to 0.47" (12mm) widths. "TZe" tape cassettes are available in
many colors and sizes. Visit
www.brother.com
for a complete list of tapes that work with your machine.
Read this manual carefully before starting and keep it in a handy place for future reference.
Printed in China
LAJ575001
English
User’s Guide
H11
NOTE
When using optional AC adapter (AD-24ESA)
1. Insert the plug on the adapter cord into the AC adapter jack on the bottom end of the label maker.
2. Insert the plug into the nearest standard electrical outlet.
For memory backup, use either AAA alkaline batteries (LR03) or Ni-MH batteries (HR03) together
when using the AC adapter.
To Next Page
