This printer can use either the AC adapter
(included) or the rechargeable Li-ion battery
(optional). Use the power supply appropriate
for your intended use.
With the rechargeable Li-ion battery installed,
this printer can be used in locations that do
not have AC power.
The battery is recharged by the AC adapter
when the battery and the battery base are
attached to the printer. In addition, if the 4 bay
battery charger (optional:PA-4BC-4000) is
used, the battery can be recharged without
using the printer.
Installing the
Rechargeable Li-ion
Battery
14
a Attach the battery base onto the printer.
For details on attaching the battery base
(optional), see its instruction manual.
b While pressing in the cover latch (1) at
the bottom of the battery base, lift up the
battery cover (2).
c Pull up the cover in the same direction
that the cover latch was pressed, and
then remove the cover.
d Insert the rechargeable Li-ion battery
into the battery compartment.
e Confirm that the hooks on the edge of
the battery cover are inserted correctly,
and then reattach the cover.
Press down on the battery cover until it
snaps into place, indicating that the
cover latch is secured.
The voltage supplied by the rechargeable
Li-ion battery fluctuates. The printing
speed may also fluctuate depending on
the voltage.
Using the Rechargeable Li-ion
Battery/Battery Base
(Optional:PA-BT-4000LI/PA-BB-
001) (TD-2120N/2130N only)
14
1
2
To Next Page
