RollMax 2400.
Specifications.
Performance…………………………………………………………………Up to 1500 sq.yd. (1260 m/sq.) per hour.
Width of Cut………………………………………………………………….24 in. (610 mm).
Length of Cut…………………………………………………………………Adjustable – Up to 125 ft. (38m).
Thickness of Cut…………………………………………………………….Power Adjustable – Up to 2 in. (51mm).
Conveyor Drive………………………………………………………………Hydraulic – Ground Speed Controlled.
Conveyor Mat………………………………………………………………...Rubber or Mintex Metal Mat.
Cutter Drive…………………………………………………………………..Hydraulic.
Cutter Blades…………………………………………………………………One Piece – Standard.
Construction………………………………………………………………….High Strength Steel.
Overall Width………………………………………………………………….132 in. (3353 mm).
Overall Length………………………………………………………………..256 in. (6502mm).
Shipping Weight.(c/w RollMax Unit)………………………………………11000 lbs. (4990kg). Approximately.
Options. Accessories.
Auto-Steer. Transport Canister.
Auto Slab Kit. Sod-Wrap Netting.
Canopy and Operating Lights. Poly Tubes.
Rotary Brush Attachment.
Net Wrap.
Outer Net Wrap.
Tractor Specifications.
Model………………………………………………………………………John Deere 5225.
Engine……………………………………………………………………..Turbo Diesel. 53 hp. (45 PTO).
Transmission……………………………………………………………..9 x 3 SyncShuttle.
Steering……………………………………………………………………Hydrostatic Power.
Rear Axle………………………………………………………………….Heavy Duty.
Tires – 2WD………………………………………………………………. Rear. 19.5-24. Front. 11L-15.
4WD………………………………………………………………...Rear. 19.5-24. Front. 12.5/80-18.
IMPORTANT
Wheel Lug Nuts should be checked for tightness after the first 20 hours of operation, and then every 100 hours.
Rear Lug Nuts………………………….250 to 275 ft.lbs.
Front Lug Nuts –2WD…………………130 ft.lbs.
4WD………………….220 ft.lbs.
Specifications subject to change without notice or obligation.
