AUTO-STEER
Sensitivity Adjustment.
On initial Set-up the Sensitivity Cable Rod End ‘A’, is
positioned ‘midway’ in the slot in the Lever Arm ‘B’.
To increase the sensitivity, (faster response):
• Loosen the Rod End Locknut ‘C’. and move
the Rod End toward the end of the Lever Arm.
To decrease the sensitivity, (slower response):
• Move the Rod End toward the Spring Column.
After adjustment, tighten the Rod End Locknut.
5-05
